Rated current In (A): 6A,10A,16A,20A,25A,32A,40A
Rated voltage Ue: 230V AC
Rated breaking capacity(A): 6KA
Rated residual current: 30mA,100mA
Tripping characteristic: B, C
Electrical endurance: 4000 cycles
Mechanical endurance:100000 cycles
Standard: BS EN 61009-1
| Part No | Description |
| WRCS106B-140B/030 | Single Module 6Amps-40Amps B Curve 30mA |
| WRCS106B-140B/100 | Single Module 6Amps-40Amps B Curve 100mA |
| WRCS106C-140C/030 | Single Module 6Amps-40Amps C Curve 30mA |
| WRCS106C-140C/100 | Single Module 6Amps-40Amps C Curve 100mA |
All-round electrical protection:
Integrates overload, short-circuit, and sinusoidal alternating earth fault protection, while guarding against direct/indirect contact risks, forming a multi-layer safety shield for circuits and personnel.
Strong durability for long-term reliability:
Boasts 4,000 electrical endurance cycles and 100,000 mechanical endurance cycles, ensuring stable performance during frequent operations, reducing replacement and maintenance needs.
Reduce fire risk:
Addresses insulation fault-caused fire risks, enhancing overall electrical system safety, compliant with BS EN 61009-1 standards for trusted performance.
