Rated current In (A): 6A,10A,16A,20A,25A,32A,40A
Rated voltage Ue: 230V AC
Rated breaking capacity(A): 6KA
Rated residual current: 30mA,100mA
Tripping characteristic: B,C
Electrical endurance: 4000 cycles
Mechanical endurance:100000 cycles
Standard: BS EN 61009-1
Type:AC,A
| Part No | Description |
| WRCN106B-140B/030 | Single Module 6Amps-40Amps B Curve 30mA |
| WRCN106B-140B/100 | Single Module 6Amps-40Amps B Curve 100mA |
| WRCN106C-140C/030 | Single Module 6Amps-40Amps C Curve 30mA |
| WRCN106C-140C/100 | Single Module 6Amps-40Amps C Curve 100mA |
