Rated current In (A): 6A,10A,16A,20A,25A,32A,40A,50A
Rated voltage Ue: 230V AC
Rated breaking capacity(lcn): 6KA,10kA
Rated residual current: 30mA, 100mA
Tripping characteristic: B,C
Electrical endurance: 4000 cycles
Mechanical endurance:100000 cycles
Standard: BS EN 61009-1
| Part No | Description |
| WRCA106B-163B/030 | Single Module 6Amps-63Amps B Curve 30mA |
| WRCA106B-163B/100 | Single Module 6Amps-63Amps B Curve 100mA |
| WRCA106C-163C/030 | Single Module 6Amps-63Amps C Curve 30mA |
| WRCA106C-163C/100 | Single Module 6Amps-63Amps C Curve 100mA |
Multiple Protection Functions:
Covers earth fault/leakage, short circuit, and overload protection. Shields devices from insulation failures—e.g., safeguards home appliances like fridges and ACs, reducing fire risks.
Lockable Handle:
Handle locks with a padlock to avoid accidental shutdowns. Ideal for public spaces, commercial buildings, or areas with kids, ensuring stable operation of critical circuits.
High Durability:
Boasts 4,000 electrical and 100,000 mechanical cycles. Lowers replacement/maintenance needs, fitting high-frequency scenarios like industrial workshops for lasting performance.
