Rated voltage(Ue): AC230V
Rated operating frequency: ±50Hz 2%
Rated insulation withstand voltage(Uimp): 4kV
Rated current(In): 6A,10A,16A,20A,25A,32A,40A
Number of N poles: 1P+N
Protection Curve: B
Operating short-circuit capacity(lcs): 6kA
Rated residual operating currentl△n: 30mA
RCD Type: AC,A
Insulation material group: IIIa
Ambient Temperature range: -5~40℃
Storage Temperature range:-25℃~+55℃
| Part No | Description |
| WAFD6B | 6A B Curve Arc Detection Device with RCBO |
| WAFD10B | 10A B Curve Arc Detection Device with RCBO |
| WAFD16B | 16A B Curve Arc Detection Device with RCBO |
| WAFD20B | 20A B Curve Arc Detection Device with RCBO |
| WAFD25B | 25A B Curve Arc Detection Device with RCBO |
| WAFD32B | 32A B Curve Arc Detection Device with RCBO |
| WAFD40B | 40A B Curve Arc Detection Device with RCBO |
