Rated current(In):6A, 10A, 16A, 20A, 32A, 40A
Rated voltage(Un): 240V AC
Breaking capacity(Icn): 6KA
Rated residual current: 30mA, 100mA
Thermomagnetic release characteristics: B,C
Electrical endurance: 4000 cycles
Mechanical endurance: 10000 cycles
Standard: BS EN 61009-1
Cable terminal capacity maximum: 16mm²
Bidirectional
| Part No | Description |
| WRCT206B-240B/030 | Double Module 6Amps-40Amps B Curve 30mA twin switches RCBO |
| WRCT206B-240B/100 | Double Module 6Amps-40Amps B Curve 100mA twin switches RCBO |
| WRCT206C-240C/030 | Double Module 6Amps-40Amps C Curve 30mA twin switches RCBO |
| WRCT206C-240C/100 | Double Module 6Amps-40Amps C Curve 100mA twin switches RCBO |
