Pole No: 1P+N,3P+N

Rated voltage Un: 240V~1P+N, 415V~3P+N

Rated current In: 16A,20A,25A,32A,40A,50A,63A

Rated residual operating current I∆:0.03A,0.1A,0.3A

Duty type as per DC component: AC, A

Rated limited short circuit current Inc: 6000A

Rated limited residual short circuit current I△€: 6000A

Rated making and breaking capacity Im: 500A(ln≤50A),630A(ln=63A)

Rated residual making and breaking capacity gm: 500A(ln≤50A),630A(ln=63A)

Rated residual non op^rated current lAno: 0.51∆n

Rated insulation voltage Ui: 500V

Rated impulse withstand voltage Uimp: 4000V

Tightening torque: 3.0N.m

Electrical life: 2000 Times

Mechanical life: 3000 Times

Operated ambient temperature℃: -25~+40

Stored ambient temperature℃: -25~+70

Pollution level: 2

Protection level: IP20

Mounting type: II

Certification: IEC/EN
