Mounting Type: Rail Mounting
Max Rated Current: 32A
Rated Voltage: 690V AC
Compatible Fuse Size: 10.3x38mm
Number of Poles: 1-4 Poles (available in single to four-pole configurations)
Application: Suitable for protecting branch circuits, lighting systems, and smaller HVAC units within commercial buildings, office complexes, and public facilities
Max Power Dissipation: 4W
Optional Feature: Available with or without indicator light (WS18-32X includes indicator light)
Certificated with CB/SEMKO/UKCA by EN60269-1
OEM Service
| Part No | Description | Fuse Size | Max Rated Current | U(v) | Number of Poles | Max Power Dissipation |
| WS18-32 | 32A Rail Mounting Fuse Holder | 10.3x38mm | 32A | 690V AC | 1P-4P | 4W |
| WS18-32X | 32A Rail Mounting Fuse Holder with Indicator Light | 10.3x38mm | 32A | 690V AC | 1P-4P | 4W |
