Mounting Type: Rail Mounting
Pole Configuration: 1P+N (1 Pole + Neutral)
Max Rated Current: 32A
Rated Voltage: 690V AC
Compatible Fuse Size: 10.3x38mm
Rated Power Dissipation: 3W
Max Power Dissipation: 4W
Optional Feature: Available with or without indicator light (WS18-32NX includes indicator light)
Application: Commercial buildings, offices, and retail spaces
Certificated with CB/SEMKO/UKCA by EN60269-1
OEM Service
| Part No | Description | Fuse Size | Max Rated Current | U(v) | Rated Power Dissipation | Max Power Dissipation |
| WS18-32N | 1P+N 32A Rail Mounting Fuse Holder | 10.3x38mm | 32A | 690V AC | 3W | 4W |
| WS18-32NX | 1P+N 32A Rail Mounting Fuse Holder with Indicator Light | 10.3x38mm | 32A | 690V AC | 3W | 4W |
INQUIRY NOW
