Rated current In(A): 6,10,16,20,25,32,40,50,63A.
Rated voltage Un: 240/400VAC.
Poles: 3P+N.
Tripping curve: B, C, D.
Residual current operating characteristic: Type A.
Rated frequency: 50/60Hz.
Rated short-circuit breaking capacity Inc: 10kA.
Rated residual operating current I△n(mA): 30,100mA.
Complies with BS EN61009-1.
Terminal capacity: IN: 16mm2, OUT: 10mm2.
Type: A.
| Product model | Description | Box Qty |
| WRCF306B-363B/030 | 3P+N 6Amps-63Amps B Curve 30mA | 40 |
| WRCF306B-363B/100 | 3P+N 6Amps-63Amps B Curve 100mA | 40 |
| WRCF306C-363C/030 | 3P+N 6Amps-63Amps C Curve 30mA | 40 |
| WRCF306C-363C/100 | 3P+N 6Amps-63Amps C Curve 100mA | 40 |
| WRCF306D-363D/030 | 3P+N 6Amps-63Amps D Curve 30mA | 40 |
| WRCF306D-363D/100 | 3P+N 6Amps-63Amps D Curve 100mA | 40 |
