Pole No: 2

Rated current(A): 80,100A

Rated voltage: 240/415V AC

Rated frequency: 50/60Hz

Rated residual operating current I∆(mA):30,100

Rated residual non operating current: 0.5l∆n

Rated conditional breaking current Inc: 6000A

Tripping duration Instantaneous tripping≤0.ls

Residual tripping current range:0.5l∆n~l∆n

Electro-mechanical endurance:4000 cycles

Connection capacity Rigid conductor up to 35mm2

Connection terminal Screw terminal

Pillar terminal with clamp

Fastening torque 2.0 Nm

Installation: On symmetrical DIN rail 35mm

Panel mounting
