Poles: 1P, 2P, 3P, 4P

Rated voltage: AC400V

Rated current: 80A, 100A, 125A

Rated insulation voltage: 500V

Impulse withstand voltage: 6kV

Thermal trip benchmark setting temperature: 30℃

Tripping characteristics: B / C / D

Breaking capacity: 10kA

Terminal capacity: 50mm²

Isolation function: Contact status indicator with red green color

Current protection action characteristics

Operational environment
a. Air temperature: -5℃ to 40℃
b. The average temperature within 24 hours shall not exceed +35℃
c. The altitude of the installation site generally does not exceed 2000m
d. Pollution level: II
e. Installation category: II, III
