HRC white porcelain body
Copper/Brass contact cap
High grade copper fuse element
Rated voltage: AC400V
Rated current: From 2A to 25A (specifically 2A, 4A, 6A, 8A, 10A, 16A, 20A, 25A)
Application: Utilized in commercial buildings, public infrastructure (e.g., railway systems, airports)
Fusing characteristics: gG/gL/aM/aR
Breaking capacity: 100KA-400V
Certificated with CE by EN60269-1
OEM Service
| Product model | Description | Functional class | U(v) | Breaking Capacity (KA) |
| FU2A08L | 2A 8.5*31.5 Fuse Link | gG/gL/aM/aR | 400V | 100KA |
| FU4A08L | 4A 8.5*31.5 Fuse Link | gG/gL/aM/aR | 400V | 100KA |
| FU6A08L | 6A 8.5*31.5 Fuse Link | gG/gL/aM/aR | 400V | 100KA |
| FU8A08L | 8A 8.5*31.5 Fuse Link | gG/gL/aM/aR | 400V | 100KA |
| FU10A08L | 10A 8.5*31.5 Fuse Link | gG/gL/aM/aR | 400V | 100KA |
| FU16A08L | 16A 8.5*31.5 Fuse Link | gG/gL/aM/aR | 400V | 100KA |
| FU20A08L | 20A 8.5*31.5 Fuse Link | gG/gL/aM/aR | 400V | 100KA |
| FU25A08L | 25A 8.5*31.5 Fuse Link | gG/gL/aM/aR | 400V | 100KA |
