Supplied with neutral cable, live busbar, neutral & earth terminal bars
Fitted with DP 40A Type A RCD Switch
Fitted with DP 100A Main Switch
Fitted with 6A-32A MCBs
Multiple cable entry knock-outs (20 & 25mm) on the top and bottom
Max cable capactiy 25mm2
Suface Mounted
Protection degree IP40
Certificated with CE/UKCA by BSEN61439-3
OEM/ODM Service
| Part No | Description |
| WMGU40616 | 4Way c/w DP 40A 30mA RCD + B6A/B16A MCB |
| WMGU40620 | 4Way c/w DP 40A 30mA RCD + B6A/B20A MCB |
| WMGUMS616 | 4Way c/w DP 100A Main Switch + B6A/B16A MCB |
| WMGUMS620 | 4Way c/w DP 100A Main Switch + B6A/B20A MCB |
| WMGUMS20 | 4Way c/w DP 100A Main Switch + B32A MCB |
| WMGUMS32 | 4Way c/w DP 100A Main Switch + B32A MCB |
Safety & Multi-Scenario Compatibility
Incorporating DP 40A Type A RCD, 100A main switch, and 6A-32A MCBs, protection degree IP40, it safeguards both standard garage equipment and ev consumer units against overload and earth leakage hazards.
Cable Compatibility & Streamlined Installation
Integrating 20mm/25mm cable entry knockouts (top/bottom) with maximum 25mm capacity, it accommodates cabling for both Garage Consumer Units and ev consumer units, streamlining installation processes.
Compliance & Reliable Performance
Holding CE/UKCA certifications and complying with BSEN61439-3, it delivers reliable performance for standard garages while providing code-compliant circuit control for ev consumer units, upholding long-term operational reliability.
