Supplied with neutral cable, live busbar, neutral & earth terminal bars
Fitted with DP 16A-40A Type A RCBO
Fitted with 20/40KA T2/1P+N Surge Protective Device
Fitted with DP 100A Main Switch.
Fitted with 6A-40A Double line switched/Type A/1P+N RCBO
Multiple cable entry knock-outs (20 & 25mm) on the top and bottom
Max cable capactiy 25㎟
Suface Mounted
Protection degree IP40
Certificated with CE/UKCA by BSEN61439-3
OEM/ODM Service
| Part No | Description |
| WMVU05-SR16 | 5Way c/w DP 16A RCBO + 20/40KA T2/1P+N SPD(2usble way) |
| WMVU05-SR20 | 5Way c/w DP 20A RCBO + 20/40KA T2/1P+N SPD(2usble way) |
| WMVU05-SR32 | 5Way c/w DP 32A RCBO + 20/40KA T2/1P+N SPD(2usble way) |
| WMVU05-SR40 | 5Way c/w DP 40A RCBO + 20/40KA T2/1P+N SPD(2usble way) |
| WMVU05-MSR16 | 5Way c/w DP 100A Main Switch + 20/40KA T2/1P+N SPD + 16A 1P+N RCBO(1usble way) |
| WMVU05-MSR20 | 5Way c/w DP 100A Main Switch + 20/40KA T2/1P+N SPD + 20A 1P+N RCBO(1usble way) |
| WMVU05-MSR32 | 5Way c/w DP 100A Main Switch + 20/40KA T2/1P+N SPD + 32A 1P+N RCBO(1usble way) |
| WMVU05-MSR40 | 5Way c/w DP 100A Main Switch + 20/40KA T2/1P+N SPD + 40A 1P+N RCBO(1usble way) |
